2000V Type W MSHA

Application:

• For use in all stationary, underground, or surface mining applications.
• For use with drills and pumps, and as portable power and temporary power supply cables.

Structure:

• Conductors：Annealed flexible stranded tin copper
• Separator：Tape separator between conductor and insulation (if necessary)
• Insulation：Ethylene-propylene rubber (EPR)
  1. core black
  2. cores black/white
  3. cores black/white/green
  4. cores black/white/green/red
  5. cores black/white/green/red/orange
• Assembly：Power and ground cores cabled together to form a round core
• Filler：rubber filled binder tape over
• Jacket：Black heavy duty CPE thermosetting

Standard:

• c(UL) listed
• MSHA listed
• ICEA Standard S-75-381/NEMA WC-58, ASTM B-172 and B-33
• CSA 2, No. 96 Portable Power Cords

Performance:

• Excellent flexibility
• Highly ozone, sun, weather and flame resistant
• Oil and heat resistant
