Application:
- For open and concealed wiring in dry locations only.
- For use in cable troughs and ventilated flexible cableways in dry locations only.
- Minimum recommended installation temperature minus 40°C (with suitable handling procedures).
- Maximum conductor temperature 90°C.
- Approved for use with ceiling fixtures.
- Armoured cable for commercial, industrial and apartment use.
Structure:
- Conductor: Copper conductor with Copper grounding wire 14AWG to 2AWG or aluminium alloy 8000 series ACM with AL groundig wire 6AWG to 750MCM
- Insulation: Cross-linked polyethylene insulation (RW90 XLPE)
- Assemble wrap: Conductor assembly paper wrapped
- Armored: Interlocked aluminum armour
- Number of conductor: Two, three or four core round laid
Standard:
- CSA C22.2 No. 51 – Armoured Cables
Performance:
- FT4 Flame retardant
- Lead free and ROHS compliant
