Application:
- ACWU 90 cables are primarily intended for exposed and concealed wiring in dry or wet locations and where exposed to the weather.
- For use in ventilated, non-ventilated, and ladder type cable trays in wet and dry locations, direct earth burial, service entrance above or below ground.
Structure:
- Conductor: Three or four compact 8000 Series ACM aluminum conductors with bare aluminum bonding wire in multi-conductor cables
- Insulation: Cross-linked polyethylene insulation (XLPE)
- Assemble wrap: Conductor assembly paper or PP tape wrapped
- Armored : Interlocked aluminum armor
- Overall Jacket: PVC jacket
- Conductor color: Black, red and white for 3 conductor; Black, red, blue and white for 4 conductor
Standard:
- CSA Standard CSA C22.2 No. 51-20（Metal-clad Cable）
Performance:
- FT4 Flame retardant
- Sunlight Resistant
